product description：
GTC, GTS Series indoor splitter, adopted by the multi-bright tin-plated die-cast zinc alloy shell, tin sealing process to ensure that the product I m anti-corrosive, anti-leak, anti-RF interference, shielding factor ≥100dB. This series of products using high-quality core, ensure excellent indicators of wideband, low loss, high isolation, high return loss.
Technical Parameters：
Table 1
Universal a splitter performance parameters
|
No.
|
project
|
unit
|
Performance parameters
|
|
1
|
Branch loss
|
Nominal value
|
dB
|
8
|
10
|
12
|
14
|
16
|
18
|
20
|
24
|
|
Tolerance
|
±1.5
|
|
2
|
Insertion Loss
|
5~65MHz
|
dB
|
<2.0
|
<1.8
|
<1.5
|
<1.5
|
<1.3
|
<1.3
|
<1.0
|
<1.0
|
|
65~550 MHz
|
<2.0
|
<1.8
|
<1.5
|
<1.3
|
<1.0
|
<1.0
|
<0.7
|
<0.7
|
|
550~750 MHz
|
<2.0
|
<2.0
|
<1.5
|
<1.6
|
<1.2
|
<1.3
|
<1.3
|
<1.0
|
|
750~1000 MHz
|
<2.5
|
<2.2
|
<1.8
|
<1.8
|
<1.5
|
<1.3
|
<1.5
|
<1.0
|
|
3
|
Reverse Isolation
|
5~65MHz
|
dB
|
>20
|
>22
|
>22
|
>24
|
>28
|
>28
|
>32
|
>32
|
|
65~550 MHz
|
>22
|
>22
|
>25
|
>25
|
>26
|
>28
|
>31
|
>31
|
|
550~750 MHz
|
>22
|
>22
|
>22
|
>25
|
>26
|
>28
|
>31
|
>31
|
|
750~1000 MHz
|
>20
|
>20
|
>22
|
>22
|
>24
|
>25
|
>38
|
>38
|
|
4
|
Return Loss
|
5~65MHz
|
dB
|
>14
|
|
65~550 MHz
|
>16
|
|
550~750 MHz
|
>14
|
|
750~1000 MHz
|
>14
|
|
5
|
Shielding attenuation
|
dB
|
≧100
|
Table 2
Universal two splitter performance parameters
|
No.
|
project
|
unit
|
Performance parameters
|
|
1
|
Branch loss
|
Nominal value
|
dB
|
8
|
10
|
12
|
14
|
16
|
18
|
20
|
22
|
|
Tolerance
|
±1.5
|
|
2
|
Insertion Loss
|
5~65MHz
|
dB
|
<3.5
|
<2.5
|
<2.3
|
<2.0
|
<1.8
|
<1.8
|
<1.5
|
<1.5
|
|
65~550 MHz
|
<4.0
|
<2.5
|
<2.5
|
<2.0
|
<2.0
|
<1.8
|
<1.3
|
<1.3
|
|
550~750 MHz
|
<4.5
|
<3.5
|
<2.8
|
<2.3
|
<2.2
|
<2.0
|
<1.8
|
<1.8
|
|
750~1000 MHz
|
<4.5
|
<3.7
|
<2.9
|
<2.7
|
<2.5
|
<2.3
|
<2.0
|
<2.0
|
|
3
|
Reverse Isolation
|
5~65MHz
|
dB
|
>22
|
>23
|
>23
|
>26
|
>26
|
>30
|
>30
|
|
